NKM105H diesel mining dump truck
Product Parameters
NKM105H 105 tons,rated loading 70 tons,42 cubic meters Tank Volume,
520HP diesel mining dump truck
equip FASTGEAR Mechanical automatic transmission 8DS260/MT
|
Vehicle Spec.
|
Unit
|
NKM105H
|
|
Total Vehicle Weight
|
KG
|
105000
|
|
Rated Loading Weight
|
KG
|
70000
|
|
Tank Cubic Volume
|
Cubic Meter
|
38(Flat),42(Stack)
|
|
Axle Loading Front/Middle/Rear
|
t
|
24+40+40
|
|
Engine Type/HorsePower
|
Hp
|
YC6K520-GT30(520hp)
|
|
Gearbox type
|
/
|
Faust 8DS260/MT(Mechanical Transmission)
|
|
Steering system
|
/
|
Full hydraulic steering
|
|
Suspension System(Front/rear)
|
/
|
Hydro-pneumatic spring/balance shaft general hanging
|
|
Braket System
|
/
|
Welded rigid tank frame /480x140
|
|
Vehicle Dimension
|
mm
|
9600*3680*4300
|
The design of a diesel mining dump truck typically includes a sturdy chassis, large wheels with deep treads for traction, and a robust suspension system to handle the rugged conditions found in mining environments. The dump bed is usually hydraulically operated, allowing it to be raised to unload its contents quickly and efficiently.
